Product Details:

Introduction

This device can monitor such parameters as ECG, RESP, SpO2, PR, NIBP and dual-channel TEMP, etc. It integrates parameter measurement module, display and recorder in one device to form a compact and portable equipment. At the same time, its built-in replaceable battery provides convenience for patient moving.

Main Features

 12.1'' TFT color LCD, multi-language interface(Simplified Chinese, Traditional Chinese, English, French, German, Turkish, Spanish Europe  Spanish Mexico Portuguese, Italian, Dutch, Romanian, Russian, Kazakh, Polish, Czech,Bulgarian, Ukraine)”

 Fanless design, quiet, energy-saving and clean, which reduces the possibility of cross-infection.

 All-round monitor for adult, pediatric and neonate.

 With standard interface, OxyCRG, trend chard, big character interface and view bed, convenient to observe.

 Waveform, parameter color and location can be set optionally.

 Operation mode: keys and buttons.

 Display up to 8-channel waveform on one screen.

 Display 7-lead ECG waveform on one screen, and with ECG step function.

 Adopt digital SpO2 technology, anti-motion and anti-ambient light interference, and measurement can be performed under the circumstance of weak filling.

 HRV analysis function.

 NIBP measurement mode: Manual/AUTO/Continuous, storage for 4800-group NIBP data.

 Review for 71 alarm events of all parameters and 60 arrhythmia alarm events.

 Drug concentration calculation and titration table functions.

 Print trend table data with one-key.

 Connect to Central Monitoring System by 3G, WiFi or wired mode.

 AC/DC, built-in rechargeable lithium battery achieve uninterrupted monitoring.

 Anti-high frequency surgical unit, defibrillation-proof(special leads are necessary).

Product Details:

To fulfill the diverse requirements of our valued clients, we are offering Multipara Monitor. The offered monitor is designed by our professionals utilizing the quality assured material and technically advanced tools in compliance with the set norms of the industry. This monitor has built-in rechargeable battery for uninterrupted monitoring. Our monitor can be availed from us at market leading rates in a promised time frame.

Features:

• Dimensional accuracy
• audible and visual alarm
• Built-in rechargeable battery

Other Details:

• Network function: connect to central monitor system, view bed, and software updating.
• Alarm Yes, audible and visual alarm, alarm events review
• ECG waveforms of 7-leads display on the same screen
• 72-hours graphic and tabular trends of all parameters
• 500 NIBP measurement data can be stored and recall
• Arithmetic analysis and S-T segment analysis
• Suitable for adult, pediatric and neonatal patient
• Built-in rechargeable battery for uninterrupted monitoring.
• The anti-high frequency surgical unit, defibrillation-proof (a requirement for special leads).
• Optional: RESP, TEMP., EtCO2, IBP, CMS, and printer.

Technical specifications:

NIBP:

• Method Oscillometry
• Modes Manual / Auto / Continuous
• Auto Measure time Adjustable
• Measurement range 10-270mmHg

SPO2:

• Measurement range 0-100%
• Accuracy 70-100%, ±2% 0-69%, unspecified

Respiration:

• Method RA-LL impedance
• Range Adult: 0-120rpm; pediatric/neonatal: 0-150rpm
• Apnea alarm yes

Optional:

• ETCO2, IBP, Printer & Networking

ECG:

• Heart rate range
• Adult: 15-300bpm
• ped/Neo 15-300bpm
• ECG waveform 2 channels
• Accuracy ±1 bpm or±1 %, Whichever is greater
• S-T segment detection: Measurement range 0.2mv~2.0mv

Pulse Rate:

• Range 20-254pm
• Accuracy ±3bpm

Temperature:

• Range 0-50 °C
• Accuracy ±0.1 °C

Request
Callback

Additional Information:

• Item Code: MM3008
• Pay Mode Terms: T/T (Bank Transfer),Other
• Port of Dispatch: Surat
• Delivery Time: Within 2 Days
• Packaging Details: Standard Packing

Product Details:

Product DescriptionUsage: FD-200C ultrasonic fetal doppler meets the fetus daily check and routine examination at home, clinic, community, and hospital.

Features: Easily and conveniently operate High-fidelity, crystal clear sound Earphone and speaker are feasible High sensitivity doppler probe Low ultrasound dosage Display with Color LCD Unique ergonomic design

Technical Specification:

• Ultrasound frequency: 2MHz
• Ultrasound intensity: <10mW/cm2
• Power supply: DC Ni-Mh rechargeable battery AC 220/110V, 50/60Hz
• FHR Measuring range: 50~240bpm
• FHR resolution: 1bpm
• FHR accuracy: Ã??â 1bpm
• Power consumption: <1W

Configuration:

• Main body
• 2MHz probe
• Ni-Mh battery
• Adaptor

Option: Carry bag 3MHz probe Earphone

Product Details:

Introduction

Photoelectric Oxyhemoglobin Inspection Technology is adopted in accordance with Capacity Pulse Scanning Recording Technology, the Pulse Oximeter can be used in measuring the pulse oxygen saturation and pulse rate through finger.The product is suitable for being used in family, hospital, oxygen bar, community healthcare, physical care in sports (It can be used before or after doing sports, and it is not recommended to use the device during the process of having sport) and etc.

Main Features:

• SpO2 value display
• Pulse rate value display, bar graph display
• Pulse waveform display
• The display mode can be changed
• Screen brightness can be changed
• Low-voltage indication: low-voltage indicator appears before working abnormally which is due to low-voltage
• Automatically power off function: when the device is under the state of measuring interface, It will automatically power off within 5 seconds if the finger falls out of the probe
• Display format can be saved after power off
